Nantong Shenwei Steel Wire Rope Co., Ltd. is one of the leading manufacturers and suppliers of 6x29fi+fc steel wire rope with color paint for lifts use 35mm 500m in China. With abundant experience, we warmly welcome you to buy durable 6x29fi+fc steel wire rope with color paint for lifts use 35mm 500m made in China here from our factory. If you have any enquiry about quotation, please feel free to email us.
Products Description
The 35mm 6×29Fi+FC Steel Wire Rope for Lifts Use with Color Paint is a premium-grade, highly flexible elevator traction and hoisting rope engineered specifically for passenger elevators, heavy-duty freight lifts, and industrial hoist systems. Utilizing the advanced 6×29 Filler (6×29Fi) equalize-lay strand construction combined with a natural/synthetic Fiber Core (FC), this cable provides exceptional bending fatigue resistance, smooth running performance, and reduced vibration. The specialized color paint surface treatment acts as an instant visual indicator for rope alignment, wear monitoring, and enhanced identification during installation and maintenance.
Product Highlights
6×29Fi Filler Wire Bending Fatigue Resistance: The 6×29 Filler structure incorporates fine inner filler wires that fill the voids between main wires, maximizing metallic contact area and significantly increasing flexing fatigue life over traction sheaves.
Fiber Core (FC) Cushioning & Sustained Lubrication: The central fiber core acts as an internal lubricant reservoir, continuously releasing protective oil during operation to minimize internal strand friction, absorb dynamic impacts, and ensure quiet drive operation.
Color Paint Coating for Easy Identification & Safety: Features a distinctive color-painted surface line/coating that allows maintenance engineers to easily detect rope twisting during installation, visually monitor outer wire wear, and quickly differentiate rope specifications on site.
Ultra-Smooth & Low-Vibration Operation: Precision-manufactured to strict diameter tolerances and roundness standards, delivering smooth, whisper-quiet travel for passenger comfort and extended drive sheave lifespan.
Technical Specifications
| Standard | ISO 4344, EN 12385-5, GB 8903 (Elevator Wire Rope Standards) |
| Lay | R.H.R.L/L.H.R.L |
| Material | carbon steel #60, #70, #72A |
| Core | FC (Fiber Core - High Grease Retention) |
| Nominal T/S | Dual Tensile (e.g., 1370/1770 N/mm²) or Single Tensile 1570 / 1770 N/mm² |
| HS code | 731210000 |
| Shipping port | Nantong port for FCL, Shanghai port for FCL or LCL |
| Payment term | 30% advanced by T/T,the balance against B/L copy ;100% L/C at sight; 30%,,100% |
| Min Order | 3000m |
| Packing | Plywood reels/Solid wooden reels/ soft coils or some special packing. |
Application
Passenger Elevators & High-Rise Lifts: Ideal as traction drive ropes for commercial office towers, residential high-rises, and hotel passenger lifts requiring high ride comfort and low noise.
Heavy-Duty Freight & Goods Elevators: Designed to handle high static loads and frequent stop-and-go cycles in industrial warehouses, shopping malls, and factory cargo lifts.
Mine Hoists & Service Lifts: Suitable for vertical guide cables, counterweight ropes, and industrial service lifts operating under controlled elevator standards.
The Storage Of Wire Rope
Wire Rope Storage Precautions:Should Be Stored In Dry And Ventilated Warehouse,Avoid Direct Sunlight Or Heat Baking. Wire Ropes Can't Be Multi-layer Stacked In Warehouse. If The Steel Wire Rope To Store A Large Amount For A Long Time,Should Often Check To Prevent Rust,After Found Rust And Recoat Lubricating Oil,If Corrosion Is Serious,The Segment Wire Rope Should Be Scrap. If The Wire Rope In The Outdoor,Should Be On Dry Ground,With Boards Underlay,And Cover With A Tarpaulin.
